Cisco Catalyst 1300 12-портов 10GE, 12-портов SFP+ комутатор
Описание
Fixed-port switch with 25 ports total: 12x 10GE copper and 12x 10G SFP+. Fanless design. Supports dynamic Layer 3 routing. Hardware stacking up to 8 switches in a stack, up to 200 ports managed as a single system with hardware failover. Includes 1x GE OOB management, Cisco Business Dashboard, Cisco Business mobile app, Cisco Network Plug and Play (PnP) agent, web user interface, SNMP, MIB, RMON, RSPAN, sFlow agent, DHCP, SCP, Traceroute, single IP management, HTTP/HTTPS, SSH, RADIUS, and more.
Power: 100-240V 50-60 Hz, internal, universal. Memory: 512 MB Flash, 1 GB DDR4 DRAM, 8 MB packet buffer. Switching capacity: 480 Gbps. Forwarding rate: 357.12 Mpps. MAC addresses: 16,000. VLAN support up to 4093 VLANs simultaneously. QoS: 8 hardware queues, strict priority and WRR. Security features: SSH, SSL, IEEE 802.1x, RADIUS authentication, MAC/Web-based authentication, STP, DHCP, IPSG, DAI, IPMB, SCT, SSD, ACLs. Dimensions: 445 x 273 x 44 mm. Rackmount option. Warranty: 99 months.
Specifications
| Management | 1x GE OOB management; Cisco Business Dashboard; Cisco Business mobile app; Cisco Network Plug and Play (PnP) agent; Web user interface; SNMP; MIB; RMON; RSPAN; sFlow agent; DHCP; SCP; Traceroute, single IP management, HTTP/HTTPS, SSH, RADIUS and etc. |
| Stackable | Hardware stacking: Up to 8 switches in a stack. Up to 200 ports managed as a single system with hardware failover |
| VLAN (number, standards) | Support for up to 4093 VLANs simultaneously; Port-based/802.1Q tag-based/MAC-based/protocol-based/IP subnet-based/Management/Private/ Guest/unauthenticated VLAN; Dynamic VLAN assignment via RADIUS; ASV; Voice/Multicast TV VLAN |
| QoS | 8 hardware queues; Strict priority and WRR; Port-based, 802.1p VLAN priority-based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP-based, Differentiated Services (DiffServ), classification and remarking ACLs, trusted QoS Queue assignment based on DSCP |
| L2 network standards | IEEE 802.3, IEEE 802.3u/ab/ad/z/x/ae/an/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC |
| IPv6 functionality | IPv6 host mode, IPv6 over Ethernet, dual IPv6/IPv4 stack; IPv6 neighbor and router discovery (ND); DAD, ICMP; DHCPv6; IPv6 over IPv4 network with ISATAP tunnel support; IPv6 QoS; ACL; First Hop Security; MLD |
| Security | SSH, SSL, IEEE 802.1x (authenticator role):RADIUS authentication and accounting, MD5 hash, guest VLAN, unauthenticated VLAN, single/multiple host mode, and single/multiple sessions; MAC/Web-based authentication; STP; DHCP; IPSG; DAI; IPMB; SCT; SSD; ACLs |
Спецификации
- Гаранция
- 99 месеца
- Тип суич
- Fixed Port
- Power Over Ethernet (PoE)
- -
- Uplink портове
- -
- Свободни (10GB) слотове
- -
- Опция за монтаж
- Rackmount
- Вентилатори
- Fanless
- Маршрутизиране
- Динамично Layer 3 маршрутизиране
- MAC адреси
- 16 000 адреса
- Захранване
- 100-240V 50-60 Hz, вградено, универсално
- Общ брой портове
- 25
- Памет (Flash, RAM)
- 512 MB (Flash), 1 GB DDR4 (DRAM), 8 MB (Packet buffer)
- Капацитет за превключване, Gbps
- 480 Gbps
- Тип основни портове
- 12x 10GE медни, 12x 10G SFP+
- Пропускателна способност, Mpps
- 357.12 Mpps
- Размери (Ш, Д, В), mm
- 445 x 273 x 44 mm
- MPN
- C1300-24XTS
